| IC rated. Suitable for direct contact with insulation |
| Aluminum construction provides greater heat dissipation. |
| Washington State Energy Code approved to meet restricted airflow requirements |
| Integral thermal protector guards against improper lamping and misuse of insulation materials. |
| 7 1/2” height allows use in 2” x 8” joist construction |
| Housing is secured to plaster frame with screws and can be removed for access to junction box. |
| Housing adjusts from 1/2” to 1 1/2” to accommodate ceiling thickness |
| Listed for through branch circuit wiring and includes several 3/4” knockouts. |
| Four pry-outs with integral strain relief simplify Romex installation. |
| Supplied with three push-in wire connectors |
| Heavy-gauge NICOR captive hanger bars provide greater stability, allowing housing to be positioned at any point within a 24” joist span, then locked in place with set screws |
| Four double-headed captive nails provide for ease of installation |
| Bars fit onto T-bar spine for quick alignment and can be permanently secured. |
| Score lines allow bars to be shortened without tools to accommodate a 12” joist span |
| 75 Watt max |
| PAR30/R30
|
