| For lighting loads only |
| Ground connection required |
| Neutral connection not required |
| Sensor can be bypassed to keep the lights on by extending the time out period to up to 30 minutes. Cannot override sensor so lights stay on indefinitely |
| Does not detect motion through glass |
|
| Troubleshooting |
| Problem: Lights do not turn on when space is occupied |
| Check sensor is not in manual-on mode (vacancy mode) |
| Sensor may be set to auto-on daylight sensing (ALD) which will not turn the lights on if there is already a significant amount of light in the room |
| Problem: Lights turn off while space is occupied |
| Sensor's timeout may be too short |
| Sensor's sensitivity may be set for low |
| Sensor may not have full view of the room |
| Problem: Lights will not turn off once space is unoccupied |
| Sensor's timeout may be set for too long |
| An external noise such as an HVAC vent may be interfering with the sensor. Try changing the sensitivity sensing to low |
| Problem: Lights turn on in vacancy mode |
| In vacancy mode, a 15 second grace period follows the timeout where the sensor will turn the lights back on if it senses motion
|
