| Light portion can switch 40-300 watts incandescent or halogen |
| Controls multiple fans as long as total fan motor does not exceed 2.5 amps |
| Solid-state control |
| Will not work on a fan with a DC motor |
|
| Troubleshooting |
| Problem: Light does not turn on/off, or flickers |
| Check that light pull chains are in "on" position |
| Make sure bulbs in use are incandescent or halogen |
| Ensure fan does not have a "current-limiting device" in the light kit |
| Problem: Fan does not come on or is stuck at low speed |
| Check that fan pull chains are in "on" position and set for the highest speed |
| Problem: Fan buzzes or hums |
| Make sure fan can be used with solid-state fan controls |
| Fully variable controls like this one can cause a fan motor to hum or buzz |
| Problem: Light switch controls the fan and the fan slider controls the light |
| Red and yellow wires are reversed |
| Problem: Light switch will only work if the fan slider is on, or vice-versa |
| One of the load wires and the common wire are switched. Check Wiring Diagram for correct wiring
|
