| Automatic voltage detection for fast, easy, out-of-the-box |
installations
| Control different load types and voltages from a single control |
| Adjust Daylight Savings Time through software, rather than |
Dip switches
| Configurable outputs allow these models to cover various types |
of applications with a single clock
| 2-circuit models are field configurable for: 2 independent outputs, |
one DPST output, or 1-channel ON pulse OFF pulse outputs
| 4-circuit models are field configurable for: 4 independent outputs, |
2 DPST outputs, 1 DPST and 2 SPST, or 2-channel ON pulse
OFF pulse outputs
| 2 second pulse option for contactor or bell ringing applications |
| New mode of operation allows for manual ON/OFF buttons to |
operate as a 2-hour override
| Non-volatile EEPROM memory protects programming indefinitely |
| Temporary or permanent overrides available via control buttons |
| Motor load rating of 1 HP 120VAC and 2 HP 240VAC |
A great retrofit solution — fits easily into other Intermatic
enclosures
Finger-safe terminals
