American Lighting LED Driver (01381)

150 watt - 24 volt - Dimmable

$174.99

Retail: $251.79

Should ship by September 19

Write the First Review

Works with
approved dimmers

Details

Part #:

AS01381

Manufacturer:

American Lighting

Manufacturer Part #:

01381

Manufacturer Description:

CCV-DR150-24

UPC Code:

714176013817

Case Size:

6 ($1,049.94/Case)

The pricing of $174.99 is per item, not per case

Function:

Driver

Energy Used:

150 watts

Volts:

Length:

9 inches

Width:

2.7 inches

Height:

1.5 inches

Mounting:

Mounting feet at both ends allows for screw down upon flat surface

Rated Current:

6.3A

Minimum Load 1W:

(non-dimming); 90W (dimming)

Input Voltage Range:

90-305V AC

Efficiency:

93%

Dimming:

1-10V DC, 10V PWM signal, and resistance

Over Current Protect:

95-106%, Constant current limiting, recovers automatically after fault condition is removed

Input Wire:

11” 18AWG SJTW x3C

Output Wire:

11” 18AWG SJTW x2C or 11” 14AWG x2C

Applications

Suitable for dry and wet locations

Features

	Hiccup mode, recovers automatically after fault condition is removed
	Over Voltage Protect: 28 - 34V Shut down o/p voltage with auto-recovery or re-power on to recover
	Over Temp Protect: Shut down o/p voltage, recovers automatically after temp goes down
	Operating Temp T-case: -40°F to 194°F (-40°C to 90°C) General ambient temperature max: 140°F (60°C)
	IP65 Rated
	Constant voltage + Constant current modes
	3-in-1 dimming capable: 1
	10VDC, 10V PWM, and resistance dimming
	Maximum wattage output up to 150W
	Built-in active Power Factor Correction (PFC)
	Class 2 design and IP65 rating
	Metal Housing with Class I design
	Auto-reset protection for short circuit and over-voltage
	cURus Listed to UL8750 Standard “Type HL” & CSA C22.2

Manufacturer's Warranty

2 Year
