20 watt Maximum 12 Output Voltage Low Profile LED Driver
Click to view larger photo
American Lighting Light Fixtures

American Lighting LED Driver (01373)

20 watt Maximum - 12 Output Voltage - 120 Input Voltage - Low Profile

$112.59
  Retail: $137.50
Quantity:
Should ship by November 7
UL Listed
RoHS Compliant
Details
Part #: AS01373
Manufacturer: American Lighting
Manufacturer Part #: 01373
Manufacturer Description:

LP-DR20-12

UPC Code: 714176013732
Case Size: 20    ($2,251.80/Case)
The pricing of $112.59 is per item, not per case
Function: Driver
Volts: 120
Mounting: Mounting foot at one end allows for screw down upon flat surface
Applications
Suitable for outdoor and indoor locations
Features
Output Volts - 12
Output Current at Max Load - 1.7A
Input Current at Max Load - 0.2A
Maximum load - 20W
Minimum Load - 8W (dimming); N/A (non-dimming)
Integrated junction box compartment with two 3/8” knockouts
Includes Over Current Protect, Short Circuit Protect, Over Voltage Protect, and Over Temp Protect
Operating temperature ranges from -22°F to 158°F
FCC Compliant
Manufacturer's Warranty
2 Year
Related Documents
Spec Sheet
