Part #:
|
AS00479
|
|
Manufacturer:
|
American Lighting
|
|
Manufacturer Part #:
|
00479
|
|
Manufacturer Description:
|
REC-DMX-5A-4Z-PLUS
|
|
UPC Code:
|
714176004792
|
|
Case Size:
|
20
($2,317.80/Case)
|
|
The pricing of $115.89 is per item, not per case
|
|
|
|
|
|
Function:
|
Receiver
|
|
Volts:
|
12-36
|
|
Length:
|
6.7 inches
|
|
Width:
|
2.3 inches
|
|
Height:
|
1.2 inches
|
|
Mounting:
|
Surface mount to hard surface
|
|
Output Wattage:
|
4 channels x (96-288)W
|
|
|
Applications
|
| Receiver for DMX signal from Trulux DMX controller for Trulux RGB, RGB+WW, or Tunable tape light |
| For indoor applications |
| Suitable for LED lighting
|
|
|
|
Features
|
| One DMX control can ‘talk’ to multiple receivers when addressed properly; A separate receiver is required for each address |
| Up to 288 watts can be connected on each of four internal circuits (each will be one address) |
| Can switch between standalone mode and DMX mode via the buttons on the decoder; Under standalone mode, there are 9 pre-programmed effects with adjustable speed and brightness |
| Requires 12-36V DC input (sold separately) and DMX controller (also sold separately, Trulux controllers recommended) for operation |
| Suitable wire types for DMX output: 12-22AWG |
| FCC Compliant |
| Operating temperature of -20°C to 50°C
|
|
|
|
Manufacturer's Warranty
|
|
|
|
|
