Part #:
|
AS00478
|
|
Manufacturer:
|
American Lighting
|
|
Manufacturer Part #:
|
00478
|
|
Manufacturer Description:
|
REC-DMX-5A-4Z
|
|
UPC Code:
|
714176004785
|
|
Case Size:
|
20
($2,799.80/Case)
|
|
The pricing of $139.99 is per item, not per case
|
|
|
|
|
|
Function:
|
Receiver
|
|
Volts:
|
12-36
|
|
Length:
|
7 inches
|
|
Width:
|
1.8 inches
|
|
Height:
|
0.75 inches
|
|
Mounting:
|
Surface mount to hard surface
|
|
Output Wattage:
|
4 channels x (60-180)W
|
|
|
Applications
|
| Receiver for DMX signal from Trulux DMX controller |
for Trulux RGB, RGB+WW, or Tunable tape light
| For indoor applications |
| Suitable for LED lighting
|
|
|
|
Features
|
| One DMX control can ‘talk’ to multiple receivers when addressed properly; A separate receiver is required for each address |
| Up to 180 watts can be connected on each of four internal circuits (each will be one address) |
| Requires Trulux DMX controller and 12-24V DC input (sold separately) for operation |
| Suitable wire types for DMX output: 12-22AWG |
| Operating temperatures of -20°C to 50°C |
| FCC Compliant
|
|
|
|
Manufacturer's Warranty
|
|
|
|
|
Related Documents
|
|
|
